| MOQ: | 1 |
| Price: | To be Quoted |
| Standard Packaging: | safety carton pack or plywood box |
| Delivery Period: | 35 working days |
| Payment Method: | T/T |
| Supply Capacity: | 1000 sets per month |
| Attribute | Value |
|---|---|
| Standard | UL 2251, IEC 62196 |
| Test Purpose | Plugs Endurance |
| Test Sample | Charge Gun |
| Speed | 0-0.8M/s Adjustable |
| Voltage | 220V |
| Test Station | 1 |
| Feature | Description |
|---|---|
| Test Sample Range | AC and DC charging gun |
| Test Station | Single station |
| Electrical Control | Mitsubishi PLC intelligent integrated control, 14-inch color human-machine touch interface |
| Operation Mode | Manual or program-controlled operation |
| Drive Mode | Servo motor drives plugging/unplugging and rotating movements with auxiliary cylinder for switch interlocking |
| Sample Fixture | Mechanical clamping, X/Y/Z three-dimensional adjustable clamp suitable for national, American, and European standard AC/DC charging interfaces |
| Automatic Flip | 90º flip capability with adjustable holding time (0-600s) |
| Test Cycles | 0-999,999 preset cycles with automatic stop |
| Test Speed | 0-800mm/s adjustable via touch screen |
| Force Measurement | 50kg range force sensor with real-time monitoring and force-time curve display |
| Safety Features | Ground protection, short circuit protection, overload protection |
|
|
