IEC60335-2-2-21.104 Torsion test apparatus of current-carrying hoses
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | KINGPO |
| Certification: | iso9001 |
| Model Number: | KP9912 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | 7000 |
| Delivery Time: | 30 |
| Payment Terms: | T/T |
| Supply Ability: | 100 |
|
Detail Information |
Product Description
IEC 60335-2-2 Clause 21.104 Current-Carrying Hoses Torsion Resistance Test Equipment
Product Information
The test equipment is designed and manufactured according to the standard requirements of
IEC60335-2-2: clause 21.104 and etc. It is used for the twist test of the vacuum cleaner current-carrying hose to verify its twist resistance strength.
Test Principle
The equipment adopts bending machine mode, and it uses PLC control and touch screen operation. The number of twists and the twist rate can be preset, it will be automatically reversed after arriving the required times and automatically stopped when the test times arrive at the requirement. During the test, the end of the current-carrying hose is fixed on the rotating fixture of the equipment, and the rest is suspended by itself. Each cycle swivels 5 turns and swivels 5 turns at a rate of 10r/min, and conducts 20 cycle tests. After the test is completed, the electric strength test is carried out on the sample.
Technical Parameters
| Applied standard | IEC 60335-2-2 |
| Applied clause | 21.104 |
| Power supply | AC220V, 50Hz (or match client's local power supply requirements) |
| Control and operation | Intelligent PLC control+7-inch touch screen operation |
| Working station | One station (can be customized, cost will be additional) |
| Drive method | Motor driven |
| Bending angle | Forward and reverse: 0-360°, can be preset on touch screen |
| Torsion speed | 0~20 turns per minute, can be preset, default 10 turns |
| Left swivel test time | 0～999999, can be preset, default 5 times |
| Right swivel test time | 0～999999, can be preset, default 5 times |
| The max. carrying weight | 10kg |
| Equipment dimension | WDH=1100×600×1400mm |
| Equipment weight | Approx. 110KG |
