| MOQ: | 1 |
| Price: | To be quoted |
| Standard Packaging: | safety carton pack or plywood box |
| Delivery Period: | 7 working days |
| Payment Method: | T/T |
| Supply Capacity: | 1000 pcs per month |
| Brand Name | Kingpo |
|---|---|
| Standard | IEC60061-3 |
| HRC | C58 To C60 |
| Material | Hardness Steel |
a) When the gauge is fully screwed home with a torque of:
There shall be a clearance** between the gauge and the edge of the rim of the lampholder.
b) In this position, and with the lampholder connected with test circuit as shown, the indicator lamp shall light.
* An increase of these values is under consideration.
** A feeler gauge with an approximate thickness of 0.08mm and width of 5mm shall be used to check that this clearance exists over the full circumference.
| Gauge Type | Model Number |
|---|---|
| E27 lamp holder gauge | "GO" GAUGE FOR LAMPHOLDERS E27 | 7006-25A-2 |
| "NOT GO" GAUGE FOR SCREW THREADS OF LAMPHOLDERS E27 | 7006-26-4 |
| GAUGE FOR TESTING PROTECTION AGAINST BULB-NECK DAMAGE AND FOR TESTING CONTACT-MAKING IN LAMPHOLDERS E27 | 7006-21-5 |
| GAUGE FOR TESTING CONTACT-MAKING AND PROTECTION AGAINST ACCIDENTAL CONTACT DURING INSERTION OF LAMPS IN LAMPHOLDERS E27 | 7006-22A-5 |
| GAUGE FOR DETECTING SIDE-CONTACTS WITH CUTTING-EDGES IN LAMPHOLDERS E27 | 7006-22B-1 |
| GAUGE I FOR CHECKING SIDE-CONTACT RESILIENCY IN LAMPHOLDERS E27 | 7006-22C-1 |
| GAUGE II FOR CHECKING SIDE-CONTACT RESILIENCY IN LAMPHOLDERS E27 | 7006-22D-1 |
|
|
