Cutting Edges E27 Lamp Holder Gauge For Detecting Side Contacts

Product Details:

Place of Origin: china dongguan
Brand Name: kingpo
Certification: iso9001
Model Number: 7006-22B-1

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: To be quoted
Packaging Details: safety carton pack or plywood box
Delivery Time: 7 working days
Payment Terms: T/T
Supply Ability: 1000 pcs per month
Contact Now

Detail Information

Brand Name: Kingpo Standard: IEC60061-3
HRC: C58 To C60 Material: Hardness Steel
High Light:

Go No Go Gauge

,

Iec 60061 3

Product Description

E27 Lampholder Gauges | Gauge for Detecting Side-contacts with Cutting-Edges in Lampholders E27 | 7006-22B-1





Purpose:



to detect the existance of cutting-edges on side-contact in E27 lamp holder.



Testing:



the gauge is screwed home in the lampholder as far as it will go. The combination is then placed with the plunger of the gauge in a horizontal position and the plunger-face is held against the helder contacts.

In this position it shall be possible to rotate the plunger in a clockwise and an anti-clockwise direction for at least an angle of 60° in both directions.

After this test the combination is placed with the plunger in a vertical position and the plunger-face is pressed against the holder contacts with a total force of 10N.

In this position it shall be possible to rotate the plunger in a clockwise and an anti-clockwise direction for at least an angle of 60° in both directions.

The lampholder complies if the torque applied for both tests does not exceed 0.4Nm.





Related gauges for E27 lamp holder:



E27 lamp holder gauge "GO" GAUGE FOR LAMPHOLDERS E27 7006-25A-2
NOT GO”GAUGE FOR SCREW THREADS OF LAMPHOLDERS E27 7006-26-4
GAUGE FOR TESTING PROTECTION AGAINST BULB-NECK DAMAGE AND FOR TESTING CONTACT-MAKING IN LAMPHOLDERS E27 7006-21-5
GAUGE FOR TESTING CONTACT-MAKING AND PROTECTION AGAINST ACCIDENTAL CONTACT DURING INSERTION OF LAMPS IN LAMPHOLDERS E27 7006-22A-5
GAUGE FOR DETECTING SIDE-CONTACTS WITH CUTTING-EDGES IN LAMPHOLDERS E27 7006-22B-1
GAUGE I FOR CHECKING SIDE-CONTACT RESILIENCY IN LAMPHOLDERS E27 7006-22C-1
GAUGE II FOR CHECKING SIDE-CONTACT RESILIENCY IN LAMPHOLDERS E27 7006-22D-1
